Inboard
profile, Outboard profile, Main deck, 01 level, 02 level & above, 1st
& 2nd platform decks, Nine cross sections, Docking plan, 13 pages of the
compartment directory, April 3, 1959. All plans are corrected to April 19,
1988 [Ships of class: John King (DDG-3), Lawrence
(DDG-4),
Claude V. Ricketts (DDG-5), Barney (DDG-6), Henry
B. Wilson (DDG-7), Lyunde McCormick (DDG-8), Towers
(DDG-9), Sampson (DDG-10), Sellers
(DDG-11), Robison (DDG-12), Hoel (DDG-13), Buchanan
(DDG-14), Berkeley (DDG-15), Joseph Strauss
(DDG-16), Conyngham (DDG-17), Semmes (DDG-18), Tattnal
(DDG-19), Goldsborough (DDG-20), Cochrane
(DDG-21), Benjhamin Stoddert (DDG-22), Richard E. Byrd (DDG-23)
& Waddell (DDG-24)].
1/96 –
1/192 SCALE
8-SHEET
+ PLAN
W2-026
PRICE:
|
|
